| DC24V | |||||||
| Motor Model | 180WD-□16030-24V | 180WD-□19020-24V | 180WD-□25015-24V | 180WD-□30010-24V | 180WD-□36030-24V | 180WD-□42030-24V | 180WD-□50030-24V |
| Rated Power(W) | 5000 | 4000 | 3900 | 3000 | |||
| Rated Currently(A) | 260 | 208 | 203 | 156 | |||
| Rated speed(rpm) | 3000 | 3000 | 2000 | 1500 | |||
| MAX Speed(rpm) | 3600 | 3600 | 2400 | 1800 | |||
| Rated torque(Nm) | 16 | 19 | 25 | 30 | |||
| MAX Torque(Nm) | 40 | 47.5 | 62.5 | 75 | |||
| Rotor inertia(Kg.cm²) | 32.6 | 45 | 55.1 | 65.2 | |||
| MTC（ms） | 58 | 60 | 61 | 65 | |||
| DC48V | |||||||
| Motor Model | 180WD-□16030-48V | 180WD-□19030-48V | 180WD-□25030-48V | 180WD-□30025-48V | 180WD-□36020-48V | 180WD-□42020-48V | 180WD-□50020-48V |
| Rated Power(W) | 5000 | 6000 | 7500 | 7500 | 7200 | 8500 | 10000 |
| Rated Currently(A) | 123 | 147 | 184 | 184 | 176 | 208 | 245 |
| Rated speed(rpm) | 3000 | 3000 | 3000 | 2500 | 2000 | 2000 | 2000 |
| MAX Speed(rpm) | 3600 | 3600 | 3600 | 3000 | 2400 | 2400 | 2400 |
| Rated torque(Nm) | 16 | 19 | 25 | 30 | 36 | 42 | 50 |
| MAX Torque(Nm) | 40 | 47.5 | 62.5 | 75 | 72 | 84 | 100 |
| Rotor inertia(Kg.cm²) | 32.6 | 45 | 55.1 | 65.2 | 77.5 | 87.7 | 97.8 |
| MTC（ms） | 50 | 52 | 54 | 57 | 60 | 64 | 67 |
| DC72V | |||||||
| Motor Model | 180WD-□16030-72V | 180WD-□19030-72V | 180WD-□25030-72V | 180WD-□30030-72V | 180WD-□36030-72V | 180WD-□42030-72V | 180WD-□50030-72V |
| Rated Power(W) | 5000 | 6000 | 7500 | 9000 | 11000 | 13000 | 15000 |
| Rated Currently(A) | 82 | 98 | 123 | 147 | 180 | 212 | 245 |
| Rated speed(rpm) | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| MAX Speed(rpm) | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 |
| Rated torque(Nm) | 16 | 19 | 25 | 30 | 36 | 42 | 50 |
| MAX Torque(Nm) | 40 | 47.5 | 62.5 | 75 | 72 | 84 | 100 |
| Rotor inertia(Kg.cm²) | 32.6 | 45 | 55.1 | 65.2 | 77.5 | 87.7 | 97.8 |
| MTC（ms） | 36 | 37 | 38 | 41 | 43 | 46 | 48 |
| DC24V | |||||||
| Motor Model | 180WD-□16030-24V | 180WD-□19020-24V | 180WD-□25015-24V | 180WD-□30010-24V | 180WD-□36030-24V | 180WD-□42030-24V | 180WD-□50030-24V |
| Rated Power(W) | 5000 | 4000 | 3900 | 3000 | |||
| Rated Currently(A) | 260 | 208 | 203 | 156 | |||
| Rated speed(rpm) | 3000 | 3000 | 2000 | 1500 | |||
| MAX Speed(rpm) | 3600 | 3600 | 2400 | 1800 | |||
| Rated torque(Nm) | 16 | 19 | 25 | 30 | |||
| MAX Torque(Nm) | 40 | 47.5 | 62.5 | 75 | |||
| Rotor inertia(Kg.cm²) | 32.6 | 45 | 55.1 | 65.2 | |||
| MTC（ms） | 58 | 60 | 61 | 65 | |||
| DC48V | |||||||
| Motor Model | 180WD-□16030-48V | 180WD-□19030-48V | 180WD-□25030-48V | 180WD-□30025-48V | 180WD-□36020-48V | 180WD-□42020-48V | 180WD-□50020-48V |
| Rated Power(W) | 5000 | 6000 | 7500 | 7500 | 7200 | 8500 | 10000 |
| Rated Currently(A) | 123 | 147 | 184 | 184 | 176 | 208 | 245 |
| Rated speed(rpm) | 3000 | 3000 | 3000 | 2500 | 2000 | 2000 | 2000 |
| MAX Speed(rpm) | 3600 | 3600 | 3600 | 3000 | 2400 | 2400 | 2400 |
| Rated torque(Nm) | 16 | 19 | 25 | 30 | 36 | 42 | 50 |
| MAX Torque(Nm) | 40 | 47.5 | 62.5 | 75 | 72 | 84 | 100 |
| Rotor inertia(Kg.cm²) | 32.6 | 45 | 55.1 | 65.2 | 77.5 | 87.7 | 97.8 |
| MTC（ms） | 50 | 52 | 54 | 57 | 60 | 64 | 67 |
| DC72V | |||||||
| Motor Model | 180WD-□16030-72V | 180WD-□19030-72V | 180WD-□25030-72V | 180WD-□30030-72V | 180WD-□36030-72V | 180WD-□42030-72V | 180WD-□50030-72V |
| Rated Power(W) | 5000 | 6000 | 7500 | 9000 | 11000 | 13000 | 15000 |
| Rated Currently(A) | 82 | 98 | 123 | 147 | 180 | 212 | 245 |
| Rated speed(rpm) | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
| MAX Speed(rpm) | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 |
| Rated torque(Nm) | 16 | 19 | 25 | 30 | 36 | 42 | 50 |
| MAX Torque(Nm) | 40 | 47.5 | 62.5 | 75 | 72 | 84 | 100 |
| Rotor inertia(Kg.cm²) | 32.6 | 45 | 55.1 | 65.2 | 77.5 | 87.7 | 97.8 |
| MTC（ms） | 36 | 37 | 38 | 41 | 43 | 46 | 48 |
