YFS150C/12-YFS150C/6
start-motors
055
| Quantity: | |
|---|---|
The Characteristics of the square automatic door motor: 1、COMPACT STRUCTURE The Square-shaped Structure Design Enables It To Fit Well Into The Instllation Space Of Automatic Doors. Usually, It Has A Small Volume And The Door Frame Travel Can Exceed The Motor. 2、HIGH POWER It Can Provide Sufficient Power To Drive The Opening And Closing Of The Automatic Door,Meeting The Requirements Of Different Door Weights And Widths, And Ensuring Smooth And Rapid Operation Of The Door Body. 3、PRECISE CONTROL It Can Provide Sufficient Power To Drive The Opening And Closing Of The Automatic Door,Meeting The Requirements Of Different Door Weights And Widths, And Ensuring Smooth And Repaid Operation of the door body. 4、HIGH STABILITY It Has Excellent Stability And Reliability, Enabling Long-term Stable Operation, Reducing The Probability Of Faults And Lowering Maintenance Costs. 1、Model：YFS150C/12 | |||
| Product name | 6 Slots round Base concaveSquare Motor | Rated Current | 2.5A |
| Model | YFS150C/12 | Rated Speed | 2800RPM |
| Color | Nature, Black, Customize | No-load speed | 234RPM |
| Number of stator slots | 12 | Gear Ratio | 1:12 |
| Magnetic Poles | 4 pairs | Rated torque with Gearbox | 0.45Nm |
| Motor Pulley | S8M powder matallurgy | Stall Torque without Gearbox | 0.65N.m |
| Rated Voltage | DC24V | Motor Socket | JST/ELP-09V |
Rated Power | 60W | IP Level | IP54 |
| 2、Model：YFS150C/6 | |||
| Product name | 6 Slots round Base concave Square Motor | Rated Current | 2.5A |
| Model | YFS150C/6 | Rated Speed | 2300RPM |
| Color | Nature, Black, Customize | No-load speed | 192RPM |
| Number of stator slots | 6 | Gear Ratio | 1:12 |
| Magnetic Poles | 4 pairs | Rated torque with Gearbox | 0.45Nm |
| Motor Pulley | S8M powder matallurgy | Stall Torque without Gearbox | 0.65N.m |
| Rated Voltage | DC24V | Motor Socket | JST/ELP-09V |
Rated Power | 60W | IP Level | IP54 |
